Sale!

10000W Complete Off-Grid Solar Panel Kit | 10KW 120V/240V Output | 28.6kWh to 43kWh Lithium Battery | 9840 Watts of Solar Panel

Original price was: €14.999,99.Current price is: €11.999,99.

  • Free Returns On All Orders
  • Free Standard Over $75
  • Free Express over $150

Package Includes
 28.67kWh Lithium Battery Bank
24x 410W Mono Solar Panel
2x 5000W 48V Off-Grid Solar Inverter Charger
2x 16.4ft 8AWG Extension Cable with MC4
4x 16.4ft12AWG Solar Cable with MC4
8x 12V 280Ah LiFePO4 Lithium Battery
4 Pairs 2AWG Battery Interconnect Cable

43kWh Lithium Battery Bank
24x 410W Mono Solar Panel
2x 5000W 48V Off-Grid Solar Inverter Charger
2x 16.4ft 8AWG Extension Cable with MC4
4x 16.4ft 12AWG Solar Cable with MC4
12x 12V 280Ah LiFePO4 Lithium Battery
7 Pairs 2AWG Battery Interconnect Cable

410W Monocrystalline Solar Panel

Rated Power: 410WSolar Cell: Mono PERC
Maximum/Peak Voltage(Vmp): 31.30VOpen Circuit Voltage(Voc): 37.50V
Short circuit current: 13.84AMaximum current: 13.10A
Output Tolerance: ±3%Temperate coefficient of Isc: 0.05%/℃
Temperate coefficient of Voc: -0.29%/℃Temperature range: －40℃～ +85℃
Frame: Aluminum alloy frameWeight: 20.5 kg
Size: 1724x1134x30 mm(With Frame)

5000W 48V Off-Grid Inverter Charger

AC Input Mode
Rated Input Voltage: 110/120VACInput Voltage Range: 90V-140VAC
Frequency: 50Hz/60Hz(auto detect)Overload/Short Circuit Protection: Circuit breaker
Efficiency: >95%AC Reverse Protection: Available
Max Bypass Overload Current: 40A
Invert Mode
Output Voltage Waveform: Pure Sine WaveRated Output Power: 5000W
Rated Output Voltage: 120VACPeak Power: 10000W
Bypass Breaker: 63ARated Battery Input Voltage: 48V
Min Starting Voltage: 44VPower Saving Mode: Load ≤25W
AC Charging Mode
Battery Type: Lead acid or lithium batteryMax Charge Current: 60A
Charge Voltage Range: 40-60VDCOvercharge Protection: Alarm and turn off charging after 1 minute
PV Charging Mode
Max Input Power: 5000WPV Charging Current Range：0-80A(can be set)
Max PV Open Circuit Voltage: 500VDCPV Operating Voltage Range: 60-145VDC
MPPT Voltage Range: 120-450VDCBattery Voltage Range: 40-60VDC
Max Output Power: 5000WCharging Short Circuit Protection: Blown fuse

280Ah LiFePO4 Lithium Battery

Battery Capacity: 280AhBattery Power: 3584Wh
Battery Voltage: 12.8VMaximum Charging Current: 250A
Maximum Discharging Current: 250AMax Charge Voltage: 14.5V
Discharge Cut-Off Voltage: 10VOperating Temperature: -4°F to 140°F
Cycle Life: ≥6000 at 50% DoD (depth of discharge)Size: 20.98*9.48*8.81inch
Weight: 63.93lbs

16.4 feet 12AWG Cables

Cable Type: Connecting Solar Panels to Charge ControllerRating Voltage: 600/1000V
Length: 5 meters（16 ft）Conductor: Tinned copper wire
AWG: 11Normal Cross Sectional Area of the Conductor (mm2): 4
Waterproof: IP 65 ProtectionTemperature: -40°F to +185°F
Connector: MC4Weight: 0.742KG

Y Branch Cable MC4 Connectors

Compatible with MC4 solar connector.Easy installation for 2 solar panels connected in parallel.
